Reach: 0.250"
12021
Special Features: Seamless compression seals are nearly 100% closed cell to prevent water from penetrating foam cell structure. Extruded skin provides a unique UV resistant barrier with design features that enhance the weather strip's sealing performance. All of Foam-Tite®'s products are CFC and phthalate free.
Compression: Recommended: 25%, Minimum: 10%, Maximum 50%, Standard Pack: 3,000’/box.
product highlights
- Overall Reach: .250" (6.35mm)
- Bulb Diameter: .200" (5.08mm)
- Kerf Depth: .225" (5.72mm)
- Kerf Width: .105" (2.67mm)
Specifications
| Part # | Box Quantity | Cut Length | Recommended Opening | Reach | Backing / Kerf Width |
|---|---|---|---|---|---|
| 12021111891500 | 3000' | Reeled | 0.080" | 0.250" | 0.105" |
| 12021112091500 | 3000' | Reeled | 0.080" | 0.250" | 0.105" |
| 12021112191500 | 3000' | Reeled | 0.080" | 0.250" | 0.105" |
| 12021114291500 | 3000' | Reeled | 0.080" | 0.250" | 0.105" |
Blacks
Tans
Whites
